TSM-105-04-S-SV-P

Name: Samtec TSM-105-04-S-SV-P
Brand: Samtec
SKU: 200-TSM10504SSVP
Price: 10.44 DKK
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

200-TSM10504SSVP

Mfr. No:

TSM-105-04-S-SV-P

Mfr.:

Samtec

Description:

Headers & Wire Housings .100 Surface Mount Terminal Strip

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Samtec TSM-105-04-S-SV-P

In Stock: 189

Stock:: 189 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 2 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

-,-- kr.

Ext. Price:

-,-- kr.

Est. Tariff:

Pricing (DKK)

Qty.	Unit Price	Ext. Price
	10,44 kr.	10,44 kr.
	8,73 kr.	803,16 kr.
	6,03 kr.	3.051,18 kr.
	5,59 kr.	5.657,08 kr.

Alternative Packaging

Mfr. Part No.:

TSM-105-04-S-SV-P-TR

Packaging:

Reel, Cut Tape

Availability:

In Stock

Price:

9,85 kr.

Min:

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Headers & Wire Housings
RoHS:
Product:	Headers
Type:	Unshrouded
Number of Positions:	5 Position
Pitch:	2.54 mm (0.1 in)
Number of Rows:	1 Row
Mounting Style:	SMD/SMT
Termination Style:	Solder Pin
Mounting Angle:	Straight
Contact Gender:	Pin (Male)
Contact Plating:	Gold
Mating Post Length:	3.05 mm (0.12 in)
Series:	TSM
Application:	Board-to-Board, Cable
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 125 C
Packaging:	Tube
Brand:	Samtec
Contact Material:	Phosphor Bronze
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	US
Current Rating:	4.1 A to 5.4 A
Flammability Rating:	UL 94 V-0
Housing Colour:	Black
Housing Material:	Liquid Crystal Polymer (LCP)
Product Type:	Headers & Wire Housings
Factory Pack Quantity:	46
Subcategory:	Headers & Wire Housings
Voltage Rating:	495 VAC
Unit Weight:	99,300 mg
